Bowers & Wilkins CCM7.3 S2 - 3-way In-ceiling Speaker (each)
HomeStore

Bowers & Wilkins CCM7.3 S2 - 3-way In-ceiling Speaker (each)

Bowers & Wilkins CCM7.3 S2 - 3-way In-ceiling Speaker (each)

Immerse yourself in high-fidelity sound with the Bowers & Wilkins CCM7.3 S2 In-Ceiling Speaker.

This premium 3-way in-ceiling speaker delivers exceptional performance for both music and home theater. Featuring a 1-inch Carbon Dome tweeter for crisp highs, a 4-inch FST Continuum cone midrange for detailed mids, and dual 5-inch Aerofoil bass drivers for deep, impactful bass, the CCM7.3 S2 ensures a rich and well-balanced listening experience.

Discreet Design, Powerful Performance

The Bowers & Wilkins CCM7.3 S2 integrates seamlessly into your home theater or living space, with a minimal footprint that disappears into the ceiling. The speaker's critically formed baffle is constructed from glass-reinforced ABS for durability, while the integrated backbox simplifies installation and minimizes sound transfer between rooms.

Key Features:

  • 3-way design for exceptional sound quality
  • 1-inch Carbon Dome tweeter for clear highs
  • 4-inch FST Continuum cone midrange for accurate mids
  • Dual 5-inch Aerofoil bass drivers for robust bass
  • Integrated backbox for easy installation and optimal sound quality

Whether you're enjoying your favorite movies or music, the Bowers & Wilkins CCM7.3 S2 In-Ceiling Speaker delivers an immersive listening experience that brings your entertainment to life.

Bowers & Wilkins CCM7.3 S2 Specifications

Drive Units:

  • 1x ø25mm (1in) Carbon Dome tweeter
  • 1x ø100mm (4in) Continuum cone FST midrange
  • 2x ø130mm (5in) Aerofoil profile bass cones

Performance:

  • Frequency range (-6dB): 52Hz - 33kHz
  • Frequency Response: 55Hz - 28kHz ±3dB
  • Sensitivity: 90dB spl (2.83Vrms, 1m)
  • Harmonic distortion (2nd and 3rd harmonics):
    • <1% 90Hz - 33kHz
    • <0.5% 120Hz - 33kHz
  • Nominal impedance: 8Ω (minimum 3.1Ω)
  • Recommended amplifier power: 25W - 200W into 8Ω

Dimensions:

  • Frame height: 355mm (14in)
  • Frame width: 355mm (14in)
  • Depth: 194.5mm (7.66in)
  • Cut-out height: 332mm (13.1in)
  • Cut-out width: 332mm (13.1in)
  • Cut-out height w/PMK: 335mm (13.2in)
  • Cut-out width w/PMK: 335mm (13.2in)
  • Protrusion: 8mm (0.3in)
  • Net weight: 9kg (19.84lb) Inc accessories

Finishes:

  • Back box: White
  • Grille: White

B&W CCM7.3 S2 Info Sheet

B&W CCM7.3 S2 Manual

B&W CCM7.3 S2 Drawing

$2,550.00
Bowers & Wilkins CCM7.3 S2 - 3-way In-ceiling Speaker (each)—
$2,550.00

More Images

Bowers & Wilkins CCM7.3 S2 - 3-way In-ceiling Speaker (each) - Image 2
Bowers & Wilkins CCM7.3 S2 - 3-way In-ceiling Speaker (each) - Image 3
Bowers & Wilkins CCM7.3 S2 - 3-way In-ceiling Speaker (each) - Image 4
Bowers & Wilkins CCM7.3 S2 - 3-way In-ceiling Speaker (each) - Image 5

Bowers & Wilkins CCM7.3 S2 - 3-way In-ceiling Speaker (each)

Immerse yourself in high-fidelity sound with the Bowers & Wilkins CCM7.3 S2 In-Ceiling Speaker.

This premium 3-way in-ceiling speaker delivers exceptional performance for both music and home theater. Featuring a 1-inch Carbon Dome tweeter for crisp highs, a 4-inch FST Continuum cone midrange for detailed mids, and dual 5-inch Aerofoil bass drivers for deep, impactful bass, the CCM7.3 S2 ensures a rich and well-balanced listening experience.

Discreet Design, Powerful Performance

The Bowers & Wilkins CCM7.3 S2 integrates seamlessly into your home theater or living space, with a minimal footprint that disappears into the ceiling. The speaker's critically formed baffle is constructed from glass-reinforced ABS for durability, while the integrated backbox simplifies installation and minimizes sound transfer between rooms.

Key Features:

  • 3-way design for exceptional sound quality
  • 1-inch Carbon Dome tweeter for clear highs
  • 4-inch FST Continuum cone midrange for accurate mids
  • Dual 5-inch Aerofoil bass drivers for robust bass
  • Integrated backbox for easy installation and optimal sound quality

Whether you're enjoying your favorite movies or music, the Bowers & Wilkins CCM7.3 S2 In-Ceiling Speaker delivers an immersive listening experience that brings your entertainment to life.

Bowers & Wilkins CCM7.3 S2 Specifications

Drive Units:

  • 1x ø25mm (1in) Carbon Dome tweeter
  • 1x ø100mm (4in) Continuum cone FST midrange
  • 2x ø130mm (5in) Aerofoil profile bass cones

Performance:

  • Frequency range (-6dB): 52Hz - 33kHz
  • Frequency Response: 55Hz - 28kHz ±3dB
  • Sensitivity: 90dB spl (2.83Vrms, 1m)
  • Harmonic distortion (2nd and 3rd harmonics):
    • <1% 90Hz - 33kHz
    • <0.5% 120Hz - 33kHz
  • Nominal impedance: 8Ω (minimum 3.1Ω)
  • Recommended amplifier power: 25W - 200W into 8Ω

Dimensions:

  • Frame height: 355mm (14in)
  • Frame width: 355mm (14in)
  • Depth: 194.5mm (7.66in)
  • Cut-out height: 332mm (13.1in)
  • Cut-out width: 332mm (13.1in)
  • Cut-out height w/PMK: 335mm (13.2in)
  • Cut-out width w/PMK: 335mm (13.2in)
  • Protrusion: 8mm (0.3in)
  • Net weight: 9kg (19.84lb) Inc accessories

Finishes:

  • Back box: White
  • Grille: White

B&W CCM7.3 S2 Info Sheet

B&W CCM7.3 S2 Manual

B&W CCM7.3 S2 Drawing
