SVS Prime Wireless Pro Soundbase

SVS Prime Wireless Pro SoundBase

The SVS Prime Wireless Pro SoundBase is a compact, high-power wireless streaming integrated amplifier that instantly modernizes any pair of passive speakers with effortless control and high-resolution sound. With a 300W (150W x 2) Class-D amp, an audiophile-grade 24-bit/192kHz DAC, and built-in streaming via DTS Play-Fi, WiFi, Apple AirPlay 2, Chromecast built-in, Spotify Connect, and Bluetooth 5.0 (aptX/AAC), it’s built to deliver clean dynamics, tight bass, and detail-rich clarity without the bulk of a traditional receiver. Hook it to your TV using HDMI ARC/eARC, connect sources through optical, RCA, or 3.5mm AUX, then add a subwoofer via the dedicated SUB Out for deeper impact. A data-rich 3.15" OLED display, six one-touch presets, app control, IR remote, and voice-assistant compatibility make it easy to run your entire system the way you actually listen today.

What It's Good At:

• Turning any passive speakers into a modern WiFi streaming HiFi system with minimal gear
• Delivering big-room dynamics and clean output with 300W (150W x 2) Class-D power
• Seamless TV integration with HDMI ARC/eARC for high-quality stereo sound and easy control
• Premium streaming flexibility: DTS Play-Fi, AirPlay 2, Chromecast, Spotify Connect, Bluetooth 5.0
• Quick access listening with 6 customizable presets (services, playlists, stations, or connected inputs)
• Expanding bass and system options with subwoofer output and variable RCA line out for other gear

SVS Prime Wireless Pro SoundBase Full Specifications:

• Power amplifier: 300 watts RMS (150 watts x 2 into 4 ohm)
• Amplifier topology: Class-D
• DAC: 24-bit/192kHz
• Rated bandwidth: 10Hz–20kHz (±1 dB)
• Signal-to-noise ratio: 100dB @ 1V input, 2 x 150W output
• Wireless streaming: DTS Play-Fi (lossless 192kHz/24-bit via Critical Listening Mode over WiFi), Apple AirPlay 2 (CD quality), Chromecast built-in (CD quality), Spotify Connect, Bluetooth 5.0 with AAC and aptX
• WiFi: Dual-band (2.4GHz and/or 5GHz)
• Inputs:
  • HDMI audio input (supports ARC and eARC)
  • Left/Right RCA input (input impedance: 20K)
  • 3.5mm AUX input (input impedance: 20K)
  • Toslink optical input (S/PDIF receiver supports sampling frequencies up to 96kHz)
  • Ethernet
  • USB service port (also powers wireless accessories)
  • 3.5mm IR control input
• Outputs:
  • Subwoofer output: 2V MAX
  • Left/Right RCA output (variable): 2V MAX
  • Front 3.5mm headphone output: 1V @ 32Ω max
  • Speaker outputs: Premium 5-way binding posts (spades, banana plugs, or bare wire)
• Controls: Smartphone/desktop app, front panel interface, IR remote, voice commands
• Presets: 6 front panel presets for one-touch access to music services, playlists, stations, and connected sources
• Display: 3.15" wide front panel OLED
• Power supply: Switch Mode Power Supply, auto switching 100–120V / 220–240V, 50/60Hz
• Fuse: 6.3A/250V
• Power cord: Detachable
• Overall dimensions (includes feet, knobs, rear in/out jacks, speaker terminals): 82.0mm (H) x 230.8mm (W) x 223.8mm (D) / 3.23" (H) x 9.10" (W) x 8.81" (D)
• Packaged dimensions: 156mm (H) x 300mm (W) x 300mm (D) / 6.14" (H) x 11.81" (W) x 11.81" (D)
• In the box: Prime Wireless Pro SoundBase, AC power cord, IR remote control, 2 x AAA batteries
• Warranty: Unconditional 2-Year Warranty

SVS Prime Wireless Pro SoundBase Q&A:

What speakers can the SVS Prime Wireless Pro SoundBase power?

It delivers 150W per channel (300W total) into 4 ohms, making it strong enough to drive most bookshelf and tower speakers with clean volume and punch.

Does it support high-resolution music streaming?

Yes. It includes a 24-bit/192kHz DAC and can stream lossless 192kHz/24-bit over WiFi using DTS Play-Fi Critical Listening Mode.

Can I connect it to my TV?

Yes. Use HDMI ARC/eARC for easy TV connection and stereo playback. For best compatibility, set the TV’s digital output to PCM stereo when needed.

What wireless streaming methods are built in?

It supports DTS Play-Fi, WiFi streaming, Apple AirPlay 2, Chromecast built-in, Spotify Connect, and Bluetooth 5.0 (aptX/AAC).

Can I add a subwoofer?

Yes. There’s a dedicated SUB Out for a powered subwoofer, letting you add deeper bass while your speakers handle the mids and highs.

What wired inputs does it include for components?

You can connect sources through HDMI ARC/eARC, optical (Toslink), RCA line in, 3.5mm AUX, and Ethernet, plus a USB service/power port.

How do I control it day to day?

Control it via the DTS Play-Fi app (phone/tablet/PC), the front panel interface, the included IR remote, or voice commands through supported voice assistant devices.

What are the 6 presets used for?

The six presets can be assigned for instant access to favorite playlists, stations, services within Play-Fi, or even connected sources like TV or game consoles.

SVS Prime Wireless Pro SoundBase Downloads:

SVS Prime Wireless Pro SoundBase Quick Start Guide
