Klipsch RP-500SA II Reference Premiere II Dolby Atmos Surround / Height Speakers

Klipsch RP-500SA II Reference Premiere Dolby Atmos® Surround/Height Speakers

Bring true cinematic height to your home theater with the Klipsch RP-500SA II Reference Premiere Dolby Atmos® Surround/Height Speakers. Purpose-built for versatility, each speaker can operate as an up-firing Atmos elevation module on top of compatible towers/monitors or as a direct-radiating height/rear surround with the flip of a switch. The Klipsch RP-500SA II is part of the Reference Premiere II Series. A 1" Titanium LTS vented tweeter mated to Klipsch’s Hybrid Cross-Section Expanded Tractrix® horn delivers crisp, dynamic highs with reduced distortion, while the 5.25" Cerametallic™ woofer (with Faraday rings) provides clean, impactful mid-bass. The sealed, internally braced MDF cabinet ensures tight response whether you’re bouncing height effects off the ceiling or mounting them as height/surround channels. Available in Ebony or Walnut finishes, the RP-500SA II integrates seamlessly with Reference Premiere systems—including RP floorstanders that accept the included Dolby Atmos jumpers—for a hemisphere of immersive sound.

What It’s Great At

• Effortless Dolby Atmos height effects with true up-firing design
• Flip-switch versatility: elevation, height, or rear surround in one model
• Clear, room-filling highs from the 1" Titanium LTS vented tweeter + Tractrix® horn
• Tight, musical mid-bass from the 5.25" Cerametallic™ woofer with Faraday rings
• Sealed, braced enclosure for precise response in multiple placements
• Easy system matching (8-ohm compatible) with included Atmos jumpers for RP floorstanders

Klipsch RP-500SA II Full Specifications

• Frequency Response: Conforms to Dolby Atmos Specifications
• Series: Reference Premiere II
• Sensitivity: Conforms to Dolby Atmos Specifications
• Power Handling (Continuous/Peak): 75W / 300W
• Nominal Impedance: 8 Ohms Compatible
• Crossover Frequency: Conforms to Dolby Atmos Specifications
• High-Frequency Driver: 1" Titanium LTS Vented Tweeter with Hybrid Cross-Section Expanded Tractrix® Horn
• Low-Frequency Driver: 5.25" Cerametallic™ Cone Woofer with Faraday rings
• Enclosure Material: MDF (Internally Braced)
• Enclosure Type: Sealed
• Inputs: Single Binding Posts
• Dimensions (H x W x D): 8.53" x 6.81" x 12.60" (21.7 x 17.3 x 32.0 cm)
• Product Weight: 9.6 lb (4.35 kg)
• Finish Options: Ebony, Walnut
• Included Accessories: Rubber Feet (8); Dolby Atmos jumpers (2) for use with Reference Premiere floorstanding speakers

Klipsch RP-500SA II Q&A

Can these be used as both Dolby Atmos elevation modules and as height/surround speakers?

Yes. With a quick flip of the mode switch, each RP-500SA II can operate as an up-firing Atmos module or as a direct-radiating height/rear surround channel.

Do they integrate with Klipsch Reference Premiere floorstanders?

Yes. The speakers include Dolby Atmos jumpers designed for compatible Reference Premiere towers, simplifying clean, secure connections.

What drivers are inside each speaker?

A 1" Titanium LTS vented tweeter with a Hybrid Tractrix® horn handles highs, while a 5.25" Cerametallic™ woofer with Faraday rings delivers mid-bass.

Are they hard to power?

No. They are 8-ohm compatible with 75W continuous/300W peak handling, making them a comfortable match for most quality AV receivers.

What enclosure type do they use?

A sealed, internally braced MDF cabinet that provides tight, controlled response in different placements.

What are the dimensions?

Each speaker measures 8.53" H x 6.81" W x 12.60" D and weighs 9.6 lb (4.35 kg).

What finishes are available?

Ebony and Walnut.

What’s included in the box?

Eight rubber feet and two Dolby Atmos jumpers for use with compatible Reference Premiere floorstanding speakers.
