Yamaha TT-S303 Manual Belt Turntable

Yamaha TT-S303 Turntable

Experience high-fidelity vinyl listening with the Yamaha TT-S303 turntable. Pair it seamlessly with other Yamaha Hi-Fi components for exceptional sound and streaming capabilities. Enjoy accurate sound reproduction with its balanced tonearm and stable rotation platter, all in a sleek, minimalist design. Plus, its built-in Phono Preamp offers versatile connectivity options, making it a perfect addition to any setup.

Yamaha TT-S303 Turntable Specs

• Turntable
  • Drive Method: Belt drive
  • Motor: DC motor
  • Rotation Speed: 33-1/3 rpm, 45 rpm
  • Rotation Speed Variation: ±2%
  • Wow And Flutter: 0.2%
  • Platter: Aluminium die-cast (Diameter 30 cm)
  • Output Level:
    • With RIAA EQ: 140 mV (-17 dBV)
    • Without RIAA EQ: 2.5 mV ± 3 dBV (1 kHz, 3.54 cm/sec)
  • Signal To Noise Ratio: 67 dB or higher (A-weighted, 20 kHz, LPF)
• Tonearm
  • Tonearm: Static balance straight tonearm
  • Effective Arm Length: 223.5 mm
  • Overhang: 19 mm
  • Stylus Pressure Adjustment Range: 0-4 g
  • Acceptable Cartridge Weight: 15.5-19 g (including headshell)
• Attached Cartridge
  • Cartridge Type: MM type
  • Output Voltage: 2.5 mV (1 kHz, 3.54 cm/sec)
  • Stylus Pressure: 3.5 ± 0.5 g
  • Cartridge Weight: 5.0 ± 0.3 g
  • Cartridge Height: 17.0 ± 0.7 mm
• Headshell Weight: 10 g (including screws, nuts and wires)
• Audio Specifications
  • Output Terminal: RCA: 1 (PHONO)
• General
  • Power Consumption: 1.5 W
  • Standby Power Consumption: 0.1 W
  • Dimension (W×H×D): 17-3/4” x 5-3/8” x 14-1/2”
  • Weight: 10.6 lbs.
