Teac TN-180BT-A3 - Bluetooth Turntable (Black)

TEAC TN-180BT-A3 Bluetooth Turntable

• Wireless Bluetooth streaming for speaker and headphone playback
• Built-in phono equalizer with selectable PHONO, LINE, and Bluetooth outputs
• Belt-drive system for reduced noise and enhanced clarity
• High-density MDF cabinet minimizes vibration and resonance
• Pre-installed Audio-Technica AT3600L VM-type cartridge
• Supports 33-1/3, 45, and 78 RPM speeds with auto-return tonearm

Experience the warmth of vinyl in the most convenient way with the TEAC TN-180BT-A3 Bluetooth Turntable. Designed for both seasoned vinyl lovers and new collectors, this high-quality turntable offers wireless Bluetooth audio streaming, a built-in phono equalizer, and a classic belt-drive system—all wrapped in a sleek, resonance-reducing high-density MDF cabinet. With support for 33-1/3, 45, and 78 RPM records, auto-return functionality, and a factory-installed Audio-Technica AT3600L cartridge, it's ready to play right out of the box. Whether connecting via Bluetooth, Line, or Phono outputs, the TN-180BT-A3 delivers clear, rich, and immersive analog sound with effortless setup.

TEAC TN-180BT-A3 Full Specifications

• Motor: DC motor with belt-drive system
• Playback Speeds: 33 1/3, 45, 78 RPM
• Wow and Flutter: 0.25%
• Signal-to-Noise Ratio: 64dB or higher (A-weighted, 20kHz LPF)
• Platter Material: Plastic
• Platter Diameter: 12" (30cm)
• Tonearm Type: Static Balance, Straight
• Effective Arm Length: 7.9" (200mm)
• Stylus Pressure Range: 0 to 5g
• Cartridge Type: VM-type (AT3600L pre-installed)
• Cartridge Output Voltage: 3.5mV (1 kHz, 5 cm/s)
• Stylus Replacement: Audio-Technica ATN3600L
• Analog Output Connectors: 1 Pair RCA Pin (Chrome-plated)
• PHONO Output Voltage: 2.4mV (±3dB)
• LINE Output Voltage: 149mV (–16.5dBV)
• Bluetooth Range: Approx. 30 ft. / 10 meters
• Bluetooth Codec: SBC
• Power Supply: AC 100–240V, 50/60Hz
• Power Consumption: <1.5W (Standby <0.2W)
• Dimensions (W x H x D): 16.5" x 4.1" x 14.0" (420 x 105 x 356 mm)
• Weight: Approx. 10.8 lbs (4.9 kg)
• Accessories Included: Rubber Sheet, EP Adapter, Dust Cover, Dust Cover Rubber Feet x2, Hinges x2, RCA Audio Cable, AC Adapter (GPE053A-120050-Z), Owner’s Manual with Warranty Card

TEAC TN-180BT-A3 Q&A

Can I use Bluetooth headphones with this turntable?

Yes, the TN-180BT-A3 has a built-in Bluetooth transmitter that lets you connect to any Bluetooth-enabled headphones or speakers.

Does it support all vinyl sizes and speeds?

It plays 33-1/3, 45, and 78 RPM records, including LPs, EPs, and SPs, with an auto-return feature for added convenience.

Do I need a separate amplifier to use this turntable?

No, thanks to the built-in phono equalizer and LINE output, it connects directly to powered speakers or standard audio systems.

Is the cartridge replaceable?

Yes, it comes with a pre-installed Audio-Technica AT3600L cartridge, and the stylus can be replaced with the ATN3600L.

How do I pair Bluetooth devices?

Simply press the BT pairing button on the turntable when your Bluetooth device is ready to connect. The button lights up when pairing is successful.

What is the turntable made of?

The cabinet is made of high-density MDF wood to reduce vibrations, unlike many plastic turntables in this range.

Can I still use it with traditional stereo systems?

Absolutely. It includes RCA outputs for both PHONO and LINE level, and even comes with an RCA cable.

Is it beginner-friendly?

Yes, it’s ready to play out of the box and is ideal for beginners with straightforward Bluetooth pairing and auto-return tonearm.

TEAC TN-180BT-A3 Downloads

TEAC TN-180BT-A3 Product Manual
