TEAC TN-400BT-X Analog Turntable with Bluetooth

TEAC TN-400BT-X Analog Turntable with Bluetooth

Experience the perfect blend of classic analog sound and modern wireless convenience with the TEAC TN-400BT-X Analog Turntable. This turntable features Bluetooth® Qualcomm® aptX™ technology, allowing you to stream music from your LP records wirelessly to your Bluetooth® headphones or speakers with high-quality audio and low latency.

Key Features:

• Bluetooth® Qualcomm® aptX™ Adaptive: Enjoy high-quality, low-latency wireless audio streaming.
• Die-cast Aluminum Platter: Provides accurate rotational speed for stable playback at 33-⅓, 45, and 78 rpm.
• S-shaped Static-balanced Tone-arm: Ensures precise tracking with a counterweight and anti-skating mechanism.
• Built-in Phono EQ Amplifier: Supports MM-type cartridges, allowing connection to conventional hi-fi systems without a phono input.
• Natural Walnut Veneer Finish: Elegant design with a laser-engraved TEAC logo.
• MM-type Cartridge from audio-technica: Includes an AT95E cartridge for accurate and musical playback.

Specifications:

• Turntable Section:

  • Type: Belt Drive
  • Motor: DC Motor
  • Rotation Speeds: 33-⅓, 45, 78 rpm
  • Wow-and-Flutters: 0.2%
  • S/N Ratio: More than 67dB (A-weighted), 60dB (unweighted, 20kHz, LPF)

• Platter:

  • Material: Aluminum Die-cast
  • Diameter: 30cm

• Tone-arm Section:

  • Type: S-shaped, Static-balanced
  • Effective Length: 223mm
  • Needle Pressure Range: 0g to 5g
  • Compatible Cartridge Weight: 4g to 8g, 14g to 18g (including Head-shell)

• Head-shell and Cartridge:

  • Model of Cartridge: audio-technica AT95E
  • Type of Cartridge: MM-type (VM-type)
  • Frequency Response: 20Hz to 20,000Hz
  • Output Voltage: 3.5mV (1kHz, 5cm/sec.)
  • Channel Separation: 20dB (1kHz)
  • Output Balance: 2.0 dB (1kHz)
  • Needle Pressure: 1.5g to 2.5g (appropriate value: 2.0g)
  • Needle Life: Approx. 300 hours (depends on conditions)
  • Coil Impedance: 2.8kohms (1kHz)
  • DC Resistance: 410ohms
  • Loading Resistance: 47kohms
  • Loading Capacity: 100 to 200pF
  • Coil Inductance: 400mH (1kHz)
  • Static Compliance: 20 × 10-6cm/dyne
  • Dynamic Compliance: 6.5 × 10-6cm/dyne (100Hz)
  • Needle Shape: Joint-oval 0.3 × 0.7mil
  • Cantilever: Aluminum Pipe
  • Vertical Tracking Degree: 20 degrees
  • Overall Dimensions: 17.0(W) × 17.2(H) × 30.5(D) mm
  • Weight: 5.7 g
  • Head-shell Weight: 10g (including nuts, screws, and wires)

• Analog Output Section:

  • Connectors: RCA jack × 1 pair (Gold-plated)
  • Output Voltage: PHONO 3.5mV +/-3dB, LINE 155mV (-16dBV)

• Bluetooth® Section:

  • Bluetooth Version: 5.2 (DUAL MODE)
  • Profile: A2DP
  • Codecs: SBC, Qualcomm® aptX™ audio, Qualcomm® aptX™ Adaptive

• Power Consumption:

  • AC Adapter Input: AC 100 - 240V, 50/60Hz
  • AC Adapter Output: DC 12V 500mA
  • Power Consumption: 1.5W or less
  • Standby Power: 0.5W or less

• Dimensions:

  • (including protrusions): 420(W) × 117(H) × 356(D) mm / 16.5"(W) × 4.6"(H) × 14.0"(D)
  • Weight: 4.9kg / 10.8lbs
  • Operating Temperature Range: 5°C to 35°C

• Included Accessories:

  • Felt Mat, EP Adapter, Counter Weight, Headshell (audio-technica AT95E installed), Platter, Dust Cover, Dust Cover Hinges × 2, RCA Audio Cable with GND wiring, AC Adapter (GPE053A-V120050-Z), Owner's Manual (including Warranty Card)

The TEAC TN-400BT-X Analog Turntable is the perfect addition to any audiophile's collection, providing high-quality audio, sleek design, and modern wireless convenience.
