Rega ND5 Moving Magnetic Cartridge
HomeStore

Rega ND5 Moving Magnetic Cartridge

Rega ND5 Moving Magnetic Cartridge

Rega ND5 Moving Magnetic Cartridge

The Nd5 moving magnet cartridge, developed over a decade, represents a groundbreaking advancement in moving magnet technology with its use of an ultra-high-powered Neodymium magnet, setting a new standard in performance. Each Nd5 is meticulously handcrafted, featuring a perfect elliptical nude diamond stylus and innovative generator geometry for exceptional channel balance and a wider soundstage. This cartridge also boasts miniaturized parallel coils for enhanced high-frequency response and comes in 100% recyclable packaging, reflecting our commitment to sustainability.

Key Features

  • Perfect elliptical nude diamond profile stylus
  • Aluminium cantilever
  • Neodymium magnet
  • Unique generator design
  • Rega 3-point mounting system
  • Lightweight, rigid PPS body
  • Handmade stereo cartridge
  • 100% recyclable packaging
  • Lifetime warranty against manufacturing defects

Nd Magnet Technology

The Nd5 utilizes the Neodymium (Nd) N55 magnet, the world's most powerful commercially available magnet, enabling superior performance and power compared to standard bar magnet designs.

Glass-Filled PPS Body

The Nd5 is encased in a zero-tolerance, injection-molded glass-filled polyphenylene sulphide (PPS) body, providing a lightweight yet highly rigid structure that minimizes stress on tonearm bearings and ensures accurate vinyl replay. This body design is inspired by our successful MC range.

Cantilever & Stylus Profile

Featuring an aluminium cantilever and a precision perfect elliptical nude diamond stylus, the Nd5 delivers exceptional tracking accuracy and captures greater detail from vinyl records.

Factory-Fitted Options

The Nd5 cartridge is available as a factory-fitted option for the multi-award-winning Planar 3 and Planar 6 turntables, offering exceptional performance and value. Factory-fitted packages are available at a discounted rate compared to separate purchases—ask your Rega dealer for details.

Rega Rebuild Scheme

Our unique pivot pad design enhances tracking ability and stylus stability by eliminating the mechanical joint between the stylus housing and the main body. If your Rega cartridge becomes damaged or worn, return it to your Rega dealer for a rebuild with a new cantilever, stylus, and pivot pad, tested and sold at a reduced price compared to other manufacturers' replacement styluses.

Technical Specifications

  • Nominal Output Voltage: 5-6mV
  • Stylus: Perfect elliptical nude diamond
  • Fixing: 3-point fixing
  • Coils: Miniaturized parallel coils
  • Window Colour: Clear smoked
  • Tracking Pressure: 1.75g

Mounting Instructions
