McIntosh MHA200 2-Channel Vacuum Tube Headphone Amplifier
McIntosh MHA200 2-Channel Vacuum Tube Headphone Amplifier
Compact yet powerful, this amplifier is designed for the discerning headphone enthusiast seeking unparalleled audio quality.
Key Features:
- Compact footprint: Just 6-1/8" (15.6cm) x 9-1/8" (23.2cm)
- 4 selectable headphone impedance ranges
- Balanced and unbalanced analog inputs
- Balanced stereo or dedicated Left & Right outputs
Unmatched Connectivity: Connect your headphones effortlessly with three options: a pair of 3-pin balanced XLR connectors, a 4-pin balanced XLR connector, and a 1/4" stereo headphone jack. The MHA200's balanced inputs allow flexible placement close to your listening position without sacrificing signal quality.
McIntosh Technologies for Superior Performance:
- Unity Coupled Circuit transformers for 4 headphone impedance ranges (32 – 100, 100 – 250, 250 – 600, 600 – 1,000 Ohms)
- Custom-designed output transformers for maximum power transfer
- High-performance toroidal power transformer for clean power
Versatile Controls:
- LOAD knob for selecting the best impedance range
- VOLUME knob for direct connection to fixed volume sources or unity gain point for variable output components
Elegant Design: The MHA200 boasts a custom-formed stainless steel chassis with a polished mirror finish, accentuating the glow of the vacuum tubes. A vintage die-cast aluminum McIntosh name badge adds a touch of classic sophistication.
McIntosh MHA200 Specifications:
Headphone Output:
- Power Output: 500mW
- Impedance Ranges: 32-100 Ohms, 100-250 Ohms, 250-600 Ohms, 600-1,000 Ohms
Electronic Specifications:
- Total Harmonic Distortion: <0.5% (250mW to rated power), <0.20% at 1W
- Intermodulation Distortion: 0.04% Typical, 0.4% Maximum
- Dynamic Headroom: 1.5dB
- Frequency Response: +0, -0.5dB from 20Hz to 20,000Hz
- Signal To Noise Ratio: 94dB
Connectivity:
- Headphone Output: 3-pin balanced XLR, 4-pin balanced XLR, 1/4" stereo jack
- Balanced Input: 1
- Unbalanced Input: 1
General Specifications:
- Vacuum Tube or Solid State: Vacuum Tube
- Power Requirement: 120V 50/60Hz, 1.5A
- Standby Power Requirement: <0.5 Watts
- Output Type: Unity Coupled Output Transformer
