Hegel H20 Power Amp - Black
Hegel H20 Power Amp
- 2 x 200 W/8 Ω
- Dual Mono
- SoundEngine
- RCA & XLR Inputs
- > 1000 Damping Factor
- 20 Bipolar Transistors
- 40 lbs
Hegel, a Norwegian manufacturer of some of the world’s finest Amplifiers. The Hegel story started back in 1988 at the Technical University in Trondheim, Norway and today Hegel's many awards and extremely positive press reviews all speak for themselves. Hegel H20 (Black): High-end Power Amplifier capable of driving every speaker.
The Hegel H20 incorporates the latest version of the Hegel FET-technology. A practical benefit of the H20 FET-technology is a more rhythmic sound. It is simply better at re-creating a bass line. Another vital element is the removal of harmonic echoes in the higher frequencies, which result in a lot more detail and still a smoother and more natural sound. The core design of the H20 is based on the H30 reference amplifier, with the best possible implementation of our patented and laser trimmed SoundEngine modules. Also designed in the timeless Hegel look, it will fit in any modern or classic home. Just one single button on the front and a solid bead blasted and anodized front panel. A truly solid design with well over 3 lbs of aluminum in the front panel alone.
Hegel H20 Specifications:
Output power: More than 200 W + 200 W in 8 ohms, Dual mono
Inputs: RCA unbalanced and XLR balanced
Speaker outputs: Two pairs of heavy-duty gold plated terminals
Input Impedance: Balanced 10k ohms, unbalanced 50k ohms
Frequency response: Less than +/- 0.2 dB deviation 20Hz - 20kHz
Phase response: Less than 2 degrees deviation 20Hz - 2 kHz
Signal to noise ratio: More than 100 dB
Crosstalk: Less than -100 dB
Distortion: Less than 0.006% at 100 W8 ohm
Intermodulation: Less than 0.01% (19 kHz + 20 kHz)
Damping factor: More than 1000
Power supply: 1000 VA dual mono, 90,000 μF capacitors
Output stage: 20 pcs 15 A 200 W high speed, ultra-low distortion bipolar transistors
Power consumption: 60 W in standby switched on
Finish: Black
Dimensions/weight: 5.7"H x 17"W x 15"D 39.7 lbs
Hegel H20 Manual
