Bluesound NODE Music Streamer

Bluesound NODE 132 Music Streamer

The Bluesound NODE Performance Music Streamer is the modern “hub” for serious hi-fi—built to bring true high-resolution streaming, flexible connectivity, and audiophile-grade conversion to any stereo or powered-speaker setup. With a precision ESS ES9039Q2M SABRE DAC, improved internal circuitry to reduce jitter and interference, and playback support up to 192 kHz / 24-bit plus DSD256, NODE delivers clean, detailed sound whether you’re streaming from today’s top services or your own library. It’s equally at home in a 2-channel system or a TV-based setup thanks to HDMI eARC and Dolby Digital decoding, while BluOS makes multi-room music simple by letting you group Bluesound players throughout the home.

For headphone listeners, NODE includes THX AAA headphone amplifier technology and a full-size 6.3mm (1/4") output for low-distortion, high-clarity listening. You can also add advanced tuning with Dirac Live Ready room correction support (upgrade required), and enjoy easy daily control with a proximity-sensing top panel and five quick-touch presets. The Bluesound NODE is part of ListenUp's Bluesound NODE Music Streaming Collection.

What It's Good At:

• Upgrading any stereo into a hi-res streaming system with an audiophile ESS SABRE DAC and low-noise circuitry
• TV + hi-fi integration via HDMI eARC and Dolby Digital decoding for a cleaner, simpler living-room setup
• Premium headphone listening with THX AAA amplification and a full-size 6.3mm headphone output
• Multi-room music that stays in sync using BluOS with dual-band Wi-Fi or gigabit Ethernet
• Streaming flexibility with AirPlay 2, Spotify Connect, TIDAL Connect, Qobuz Connect, Roon Ready, and two-way Bluetooth
• Room-tuning readiness with Dirac Live Ready output support (analog/digital) for better in-room clarity and balance

Bluesound NODE Full Specifications:

• Model Information
  • SKU: N132
  • Wireless speaker: No
• Audio
  • Supported audio file formats: MP3, AAC, WMA, WMA-L, OGG, ALAC, OPUS
  • Supported high-quality audio file formats: FLAC, MQA, WAV, AIFF, MPEG-4 SLS
  • Native sampling rates: up to 192 kHz
  • Bit depth: 16–24
  • Signal-to-noise ratio: -118 dB
  • Distortion: THD+N, 0.0007%
  • DSD support: DSD256
  • Audio controls & EQ: BluOS Controller App
  • Headphone continuous output power (THD < 0.1%):
    • 160 mW, 16Ω
    • 230 mW, 32Ω
    • 53 mW, 250Ω
    • 22 mW, 600Ω
  • Supported multi-channel audio formats: Dolby Digital®
  • DAC: ESS ES9039Q2M
  • Dirac Live output support:
    • Analog: RCA Stereo
    • Digital: Optical, Coaxial
    • The USB Output does not support Dirac Live
• Software & Integrations
  • Operating system: BluOS
  • Supported network file sharing: Server Message Block (SMB) up to 200,000 files
  • 3rd-party integrations: AirPlay 2, Spotify Connect (also support for Spotify Lossless), Tidal Connect, Qobuz Connect, Roon Ready, Dirac Live Ready
  • App controller operating system: iOS, Android, Windows, macOS
  • Album art supported: JPG, PNG
  • Control system integrations: Crestron, Control4, RTI, ELAN, URC, Lutron, Josh.ai
  • Processor: ARM® Cortex™-A53, Quad-Core, 1.8GHz per core
  • Music services & internet radio: 23+
  • Voice control integrations: Amazon Alexa Skills
• Connections
  • Power supply: Universal bi-pin AC cord input (100–240AC)
  • Optical/analog input: Combo – Mini TOSLINK / Stereo 3.5mm
  • HDMI input: HDMI eARC
  • Coaxial output: RCA
  • Optical output: TOSLINK digital optical
  • Ethernet/LAN: Ethernet RJ45, Gigabit 1000 Mbps
  • Wi-Fi built in: Wi-Fi 5 (802.11ac), dual-band
  • Bluetooth quality: Bluetooth 5.2 aptX Adaptive
  • Bluetooth connectivity: Two-way (transmit & receive)
  • USB IN: Type A (Fat32 formatted) – External Storage only; Local Server Mode
  • Audio output: Analog RCA Stereo with Fixed option; USB Audio 2.0 (Type A)
  • Headphone output: 6.3mm Stereo; Bluetooth
  • Subwoofer output: RCA x 1; Wireless to PULSE SUB+
  • IR input: 3.5mm Jack
  • Trigger out: 12 Volt
• User Interface & Control
  • IR optical built in: IR Sensor Built In – front panel with IR Remote Learning
  • Status indicator: LED x 2
  • Volume control buttons: Touch Slider LED
  • Proximity sensor: Yes
  • Play/Pause button: Touch LED
  • Preset buttons: Touch LED x 5
• General
  • Finish: Black or White: Matte Satin Paint
  • Product dimensions: 220 x 46 x 146 mm (W x H x D); 8.7 x 1.8 x 5.7 in (W x H x D) (non-metric measurements are approximate)
  • Included accessories:
    • 120V AC Power Cord
    • 230V AC Power Cord
    • Stereo RCA to RCA Cable
    • Ethernet Cable
    • Mini Jack to Toslink Adapter
    • Safety/Warranty Guide
    • Quick Setup Guide
    • Dirac Live Ready Info Card
  • Storage environment: -10°C to 50°C, 20% to 80% relative humidity
  • Product weight: 1.09kg / 2.4lbs

Bluesound NODE Q&A:

What does the Bluesound NODE do?

NODE is a high-performance music streamer that connects to your existing amp, receiver, or powered speakers so you can play hi-res music from streaming services, internet radio, and your personal library.

Can I connect NODE to my TV?

Yes. NODE includes HDMI eARC and supports Dolby Digital®, making it a strong choice for improving TV audio through your hi-fi system.

Does NODE support Apple AirPlay 2 and Spotify/TIDAL streaming?

Yes. It supports AirPlay 2, Spotify Connect (including support for Spotify Lossless), TIDAL Connect, and Qobuz Connect for convenient, app-native playback.

Is this streamer compatible with Roon?

Yes. NODE is Roon Ready, so it can be used as a Roon endpoint on compatible networks.

How good is it for headphones?

NODE includes THX AAA™ headphone amplifier technology and a full-size 6.3mm headphone output, designed for low distortion and high clarity across a wide range of headphone impedances.

What audio quality and formats does it support?

NODE supports up to 192 kHz sampling, 16–24-bit depth, and DSD256, along with common formats like MP3/AAC and hi-quality formats such as FLAC, MQA, WAV, and AIFF.

Does it have room correction?

NODE is Dirac Live Ready (available upgrade). Dirac Live output support is available on analog RCA stereo and digital optical/coaxial outputs (USB output does not support Dirac Live).

How does multi-room audio work with NODE?

Using BluOS, you can group NODE with other Bluesound players over dual-band Wi-Fi or gigabit Ethernet for synchronized, high-quality audio throughout your home.

Bluesound NODE Downloads:

Bluesound NODE Manual
Bluesound NODE Data Sheet
Bluesound NODE Quick Start Guide
