Arcam Radia A5 Integrated Amplifier
ARCAM A5 Radia Integrated Amplifer: Immerse Yourself in Your Favorite Music
The ARCAM A5 Radia is a powerful integrated amplifier designed to deliver exceptional sound quality for intimate listening experiences.
ARCAM Legacy of Amplification
Drawing on over 45 years of amplifier design expertise, the A5 Radia is meticulously crafted with premium components to ensure the most accurate and detailed music reproduction. This tradition of excellence started in 1976 with the A&R Cambridge A60 amplifier, and the A5 Radia continues this legacy.
Stream Music with Bluetooth Convenience
Enjoy the ease of wireless music streaming with the A5 Radia's built-in Bluetooth featuring Qualcomm AptX Adaptive technology. This advanced codec ensures high-definition audio playback, so you can hear every detail of your favorite songs from your phone or tablet. The A5 Radia also functions as a Bluetooth headphone receiver, allowing for private listening sessions.
High-Resolution Audio Support
Experience the full potential of your digital music collection with the A5 Radia's high-resolution digital audio inputs. These inputs can handle audio data far exceeding the quality of CDs, delivering an uncompromised listening experience.
Dedicated Phono Stage for Vinyl Enthusiasts
The A5 Radia features a high-performance phono stage specifically designed to amplify the signal from your turntable. This ensures your vinyl records sound rich, clear, and engaging, just as the artist intended.
Immerse yourself in your favorite music with the ARCAM A5 Radia Hi-Fi Integrated Amplifier. Experience the difference that exceptional sound quality can make.
ARCAM A5 Radia Specifications
Continuous Power Output (0.5% THD), Per Channel
- 2 channels driven, 20Hz - 20kHz, 8Ω: 50W
- 2 channels driven, 1kHz, 4Ω: 75W
- Harmonic Distortion, 80% power, 8Ω at 1kHz: 0.003%
Analogue Inputs
- Number of Inputs: 3 (RCA pairs)
- Signal/Noise Ratio (A-wtd, ref. 50W, 1V input): 106dB
- Frequency Response: 20Hz—20kHz ± 0.2dB
Phono (MM) Input
- Input Impedance: 47kΩ + 100pF
- Frequency Response (ref. RIAA curve): 20Hz—20kHz ± 1dB
Digital Inputs
- Supported Sample Rates (kHz):
- Coaxial (RCA): 192, 176.4, 96, 88.2, 48, 44.1
- Optical (Toslink): 192, 176.4, 96, 88.2, 48, 44.1
- Bit Depths (bit): 24, 16
- Frequency Response (filter 1): 20Hz—20kHz ± 0.2dB
- Signal/Noise Ratio (A-wtd, ref. 50W, 0dBFS): 109dB
Headphone Output
- Maximum Output Level (RMS) into 32Ω/300Ω: 2.5V/5V
- Load Range: 16Ω - 2kΩ
General
- Mains Voltage: 100V or 110–120V or 220–240V, 50–60Hz
- Power Consumption (Maximum): 350W
- Power Consumption (Standby): <0.5W
- Dimensions (W x D x H including speaker terminals): 431 x 344 x 83mm
- Weight (Net): 8kg
- Weight (Packed): 11kg
Supplied Accessories
- Mains lead(s)
- Remote control with 2 x AAA batteries
- Quick Start Guide
- Important Safety Instructions
ARCAM A5 Spec Sheet
Arcam Radia A5 A15 A25 Owners Manual
Arcam Radia Remote
