Velodyne Acoustics Impact X 15 Subwoofer
Velodyne Acoustics Impact X 15 Subwoofer
The Velodyne Acoustics Impact X 15 is the flagship of the Impact X series, featuring a massive 15-inch driver and a high-power amplifier for truly room-shaking bass. Its flow-optimized rear slot bass reflex design and robust MDF cabinet are engineered to reach down to 18–19 Hz, making it ideal for demanding home theater installations and large living spaces. A 1,000 W dynamic / 550 W RMS Class D amplifier, 9 DSP modes, and advanced control options keep the Impact X 15 both powerful and precise. With a refined flat matte black vinyl finish and dimmable display, it delivers reference-level low-frequency performance while maintaining a clean, understated appearance.
Impact X 15 Full Specifications:
- Driver: 15″ front-firing driver
- Amplifier Type: Class D
- Amplifier Power (Dynamic): 1000 watts
- Amplifier Power (RMS): 550 watts
- Frequency Response (±3 dB): 23 – 180 Hz
- Frequency Response (±10 dB): 18 – 220 Hz
- Low-Pass Crossover: 50 – 180 Hz (12 dB/octave)
- Phase Control: 0 / 180 degrees
- Cabinet Design: 22 mm MDF with 30 mm front baffle
- Magnet Structure: Dual ferrite magnet motor
- Woofer Construction: 15″ high-excursion double vented basket driver with polypropylene membrane and convex cone
- Voice Coil: Four-layer 3″ / 76 mm voice coil
- DSP Presets: 9 DSP modes adjustable via remote control
- Protection: Anti-clipping circuitry
- Inputs: Gold-plated Stereo/LFE RCA, nickel-plated high-level in
- Outputs: Gold-plated Stereo/LFE RCA
- Power Selector: Off / Auto / On
- Display: Dimmable front display
- Enclosure Type: Bass reflex with special flow-optimized rear slot design
- Finishes: Flat matte black vinyl
- Dimensions (W × H × D): 44 cm × 48 cm × 59 cm (incl. feet and connectors)
- Weight (Approx.): 35 kg
- Shipping Weight (Approx.): 40 kg
Impact X 15 Q&A:
- What type of room is the Impact X 15 designed for?
- It is designed for large living rooms and dedicated home theaters requiring very deep, high-output bass.
- How is the Impact X 15 different from the Impact X 12?
- It offers a larger 15″ driver, more amplifier power, lower bass extension, and 9 DSP modes.
- What is special about the rear slot bass reflex design?
- The flow-optimized rear slot port improves airflow, reduces port noise, and enhances efficiency.
- Can the Impact X 15 be used for music as well as movies?
- Yes, its precise driver and tuning controls make it suitable for both music and home theater use.
- How many DSP modes does the Impact X 15 offer?
- It offers nine DSP presets accessible via remote control.
- Is the Impact X 15 difficult to place due to its size?
- Although large and heavy, its front-firing driver and rear port allow flexible placement with adequate rear clearance.
- What are the dimensions and weight of the Impact X 15?
- The cabinet measures 44 cm × 48 cm × 59 cm and weighs approximately 35 kg.
- What finish is available for the Impact X 15?
- It comes in a flat matte black vinyl finish.
Impact X 15 Downloads:
Velodyne Acoustics Impact X Subwoofer Manual
