Sony STR-AZ5000ES 11.2 Channel 8K A/V Receiver

Enhance Your Home Theater Experience with the Sony STR-AZ5000ES Receiver

Experience an audio revolution in your home entertainment setup with the Sony STR-AZ5000ES Receiver, setting a new standard in performance and quality. As Sony's first 11.2 CH 8K A/V Receiver, it redefines the audio landscape with its renowned ES quality. Engineered for integrators, this receiver offers unmatched configurability, flexible connectivity, and advanced IP control, seamlessly integrating with leading control systems. The STR-AZ5000ES is a comprehensive solution that combines exceptional audio/visual performance with installation-friendly features.

Delve into Superior ES Sound Quality

Boasting 130 watts, the STR-AZ5000ES delivers an immersive audio experience, ensuring crystal-clear music reproduction and enveloping object-based surround sound. Immerse yourself in the magic of Dolby Atmos, DTS:X, and 360 Reality Audio support, elevating your auditory adventure to new heights.

Unlock the Potential of Full 8K & 4K/120 Compatibility

Indulge in the brilliance of full 8K & 4K/120 quality, seamlessly transmitted from source to screen through four 8K & 4K/120 HDMI inputs and two outputs (a total of 7 in/2 out). HDMI 2.1 support guarantees an exceptional gaming experience with minimal latency, incorporating features like Auto Low Latency Mode (ALLM) & Variable Refresh Rate (VRR).

Tailored for Seamless Integration in Your Home

With a focus on flexibility and seamless integration, the STR-AZ5000ES offers support for "Works with SONOS" certification and seamlessly integrates with leading control systems like Control4, Savant, Crestron, and OvrC. Tailor your setup to your preferences with ease.

Immerse Yourself with 360 Spatial Sound Mapping

Sony's exclusive 360 Spatial Sound Mapping technology, in conjunction with the innovative Digital Cinema Auto Calibration IX, crafts an immersive sound field that dynamically adapts to your environment. It's an audio experience that truly transforms your space.

Sony STR-AZ5000ES Specifications

Input and Output Terminals

• Composite Monitor Out: 2
• Opt: 2
• Coax.: 1
• Analog Audio In: 4
• Pre Out (Subwoofer): 2
• USB Front(ver) / Rear(ver): 1/0
• Ethernet Port (Power over Ethernet): 1(0)

HDMI Supporting HDCP2.2 In/Out

• HDMI Input supporting HDCP2.2(Front): 6(0)
• HDMI Output supporting HDCP2.2: 2

Speaker Output Terminals

• Front A
• Center
• Surround

Auto Speaker Calibration

Calibration Features

• D.C.A.C. IX / D.C.A.C. EX / Advanced D.C.A.C. / D.C.A.C.: D.C.A.C. IX
• Speaker Relocation: Yes
• Phantom Surround Back: Yes
• Automatic Phase Matching: Yes
• Calibration Mic: Stereo

Decoding Format for HDMI

• DSD: Yes (Up to 2.8MHz 5.1ch)
• LPCM: Yes (Up to 192kHz/24 bit 7.1ch)
• DTS HD MA / DTS HD HR: Yes/Yes
• Dolby TrueHD/Dolby Digital Plus: Yes/Yes
• DTS / DTS-ES (Matrix6.1 / Discrete6.1): Yes/Yes
• DTS 96/24: Yes
• DTS:X: Yes
• Dolby Dual Mono: Yes
• Dolby Atmos: Yes

Decoding Format for USB/Network Client

• Hi-Res Format
• DSDIFF(DSD), DSF, WAV(LPCM), AIFF(LPCM), FLAC, ALAC

Custom Install & Control Features

Zone2 Audio

• 2nd A: Speaker(Variable) / Line (Variable, Fixed) / HDMI(Fixed)

IR Repeat (In/Out)

• Yes(1/2)

General Features

Power Consumption

• 500W

GUI (Graphical User Interface)

• Yes

Power Requirement

• 120V 60Hz

Auto Standby

• Yes

Attachment

• Calibration microphone
• Calibration mic stand
• FM wire antenna
• AC power cord
• Remote control
• R03 (size-AAA) batteries
• Front cover

Size & Weight

Dimensions (W x H x D)

• 430x194x440mm

Weight

• 19.2kg

Video Features

A/V SYNC

• Yes(Variable)

4K 60p 4:4:4 Support

• Yes

3D over HDMI

• Yes

HDR (High Dynamic Range)

• Yes(HDR10, Hybrid Log Gamma, Dolby Vision)

Audio Return Channel

• Yes

BRAVIA® SYNC™ (CEC Control)

• Yes (System Audio Control, System Power Off, RC Pass Through, Language Follow, One-Touch Play)

4K Output

• HDMI Video Output Capability: 8K, 4K, 1080p, 1080/24p, Deep Color (up to 36 bit), Triluminous Color (xvYCC)

HDMITM Pass Through

• Standby Through: Yes

Audio Features

Sound Enhancement Technologies

• Pure Direct
• DSD Native Playback
• Center Speaker Lift Up
• In-Ceiling Speaker Mode

Network Connectivity

Network features

• Bluetooth Receiver
• Bluetooth Transmitter
• Wi-Fi

Spotify Connect

• Yes

Amplifier

Number of Amp. Channels

• 11ch

Power Output

• Front: 130W + 130W (8ohms, 1kHz, THD 0.9%)

Speaker Impedance

• 4ohms-16ohms

Sound Field

• 2ch Stereo
• Direct
• Auto Format Decoding
• Multi Stereo
• Audio Enhancer

Tuner Features

FM/AM

• Yes/-

Preset Channel (Sirius/XM/FM/AM)

• TTL30 (30/0)
