Onkyo TX-8470 Hi-Fi Network Stereo Receiver

Onkyo TX-8470 Hi-Fi Network Stereo Receiver - 2 Channel Hi-Fi Bliss

Designed for audiophiles, the Onkyo TX-8470 Hi-Fi Network Stereo Receiver merges superior sound fidelity with advanced connectivity options, delivering a seamless home entertainment experience.

Onkyo TX-8470 Features and Benefits:

Optimized Two-Channel Stereo Receiver

• High-Resolution Sound: Focused two-channel stereo design for refined audio output.
• Premium Components: Gold-plated terminals and audio-grade capacitors ensure clean sound.
• Dedicated Amplifier: High current drive maximizes loudspeaker performance for superior sound reproduction.

Vinyl-Ready Design

• Discrete Op Amp Circuitry: Isolated MM/MC phono board keeps delicate phono signals free from distortion.
• Vinyl Playback: Designed to enhance the clarity and performance of your vinyl collection.

Built-In Audiophile Streaming

• High-Resolution Streaming: Compatible with Roon, Tidal, Deezer, and more for effortless access to your favorite music.

Smart Home Integration

• Modern Connectivity: Built-in compatibility with Apple and Google assistants for seamless smart home integration.

Onkyo TX-8470 Hi-Fi Features

• Premium 2-Channel DAC: AKM’s 32bit/768kHz DAC (AK4452) supports wide range signals with low power consumption and minimal distortion.
• High-Current Class G Amplifier: Efficiently reproduces audio signals with low negative feedback for greater transparency and dynamic range.
• Gold-Plated Terminals and RCA Inputs: Ensures optimal signal transfer with minimal degradation.
• Custom Capacitors and Power Supply: Delivers dynamic and lifelike sound reproduction.
• HDMI ARC: Simplifies setup with a single cable for audio playback and device control.
• 110W/Channel Output: Provides robust power for immersive listening experiences.

Onkyo TX-8470 Specifications:

Amplification

• Power Output: 110W/ch (8Ω, 20-20kHz, 0.08% THD, 2ch driven)
• Amplifier Type: Class G Amplifier

HDMI and Video Inputs

• Inputs: 4 HDMI In, 1 HDMI Out (ARC)
• Video Support: 8K/4K Ultra HD

Audio In/Out

• HDMI: 4 inputs
• RCA: 3 inputs
• Optical: 2 inputs
• Coaxial: 1 input
• Phono Input: MM/MC selectable
• USB: 2 inputs
• Preout: 1 + Zone 2
• Subwoofer Output: 1

Key Features

• High-Current Class G Amplifier
• HDMI 8K and ARC support for AV connectivity
• AM/FM Tuner
• Bluetooth®
• Supports Spotify, Amazon Music HD, Tidal, Deezer, TuneIn Radio, Pandora, and works with Sonos
• Dedicated MM/MC Phono Circuit Board
• Multiroom Broadcast via Wi-Fi; Roon Ready
• Chromecast built-in and Airplay capable

Onkyo TX-8470 Specification Sheet
Onkyo TX-8470 Owner's Manual
