NAD T778 Home Theater Receiver
NAD T 778 AV Surround Sound Receiver
The NAD T 778 AV Surround Sound Receiver is built for listeners who want true home-cinema impact without sacrificing musical detail. Its 9-channel HybridDigital™ amplification delivers clean, controlled power for immersive movie soundtracks, lifelike dialogue, and dynamic gaming audio—while maintaining the refinement NAD is known for.
For room-specific accuracy, the T 778 pairs advanced surround processing with Dirac Live Room Correction, helping correct acoustic issues that can blur imaging and tonal balance. And because home theatre standards evolve quickly, NAD’s MDC modular architecture is designed to support future upgrades—so your system can grow without replacing the entire receiver.
With modern HDMI connectivity, high-resolution streaming capability, multiple subwoofer outputs, and an integration-friendly design for enthusiast or custom-install setups, the T 778 is a premium centerpiece for high-performance home theatres and media rooms.
What It's Good At:
- Cinematic, full-room immersion with 9 channels of HybridDigital™ amplification for powerful, controlled surround sound
- More accurate in-room sound using Dirac Live Room Correction to improve imaging and tonal balance
- Future-ready performance via NAD’s MDC modular design for long-term upgradeability
- Clean dialogue and impactful dynamics that stay composed from quiet scenes to explosive peaks
- Flexible bass management with multiple subwoofer outputs for smoother, more even low-end response
- Modern system compatibility with HDMI support for today’s video sources plus high-resolution streaming capability
NAD T 778 Full Specifications:
- Amplifier
- Power (8 Ohms): 140W (21.5dBW)
- Power (4 Ohms): 170W (22.3dBW)
- Full Disclosure Power (all channels driven simultaneously at full bandwidth at rated distortion): 9 x 85W
- Power (8 Ohms): 165W (22.2dBW)
- Power (4 Ohms): 280W (24.5dBW)
- Total harmonic distortion at rated power: <0.08%
- IM distortion at 1/3 rated power: <0.03%
- Damping factor: >300 (20Hz–1kHz, 8 ohms)
- Input sensitivity and impedance: 1.12Vrms (ref. 8 Ohms, VOL at 0dB)
- Frequency response: +0.3/-0.8dB (ref. 1kHz, 20Hz–20kHz)
- Signal/noise ratio: >100dB (ref. rated power at 8 Ohms, A-Weighted)
- Signal/noise ratio: >85dB (ref. 1W at 8 Ohms, A-Weighted)
- Preamplifier
- Frequency response: ±0.3dB (ref. 20Hz–20kHz)
- Signal-to-noise ratio: >100dB (ref. 2V, A-Weighted)
- Total harmonic distortion: <0.01%
- Input sensitivity: 245mVrms (ref. 2V)
- Maximum output level: >4.5Vrms
- Input Sensitivity: 6.2mVrms (ref. 2V) (ref. 20Hz–20kHz)
- Signal-to-noise ratio: >80dB (ref. 2V, A-Weighted)
- Maximum Input Level: >90mVrms (1kHz)
- Power Consumption
- Standby power: <0.5W (full standby)
- Dimension and Weight
- Unit Dimensions (W x H x D): 435 x 140 x 430mm (Gross)*
- Net Weight: 12.1kg (26.7lb)
- Shipping Weight: 15.5kg (34.2lb)
- *Specifications subject to change without notice.
NAD T 778 Q&A:
- What makes the NAD T 778 a great choice for a premium home theatre?
- It combines 9-channel HybridDigital™ amplification with advanced surround processing to deliver powerful dynamics, clear dialogue, and an immersive cinematic soundstage.
- Does the T 778 include room correction?
- Yes. It features Dirac Live Room Correction, which measures your room and helps correct acoustic problems to improve tonal balance and imaging.
- How many amplifier channels does the NAD T 778 have?
- The T 778 provides 9 channels of amplification, designed to deliver efficient, high-impact surround performance.
- What does NAD’s MDC modular design do for buyers?
- MDC (Modular Design Construction) is built for long-term ownership—allowing the receiver to adapt as technologies and formats change through upgradeable modules rather than full replacement.
- Is the T 778 suitable for both music and movies?
- Yes. NAD’s design focus emphasizes musicality and control, so the T 778 is engineered to sound refined with music while still delivering cinematic power for films and gaming.
- How does the T 778 handle bass management and subwoofers?
- It includes multiple subwoofer outputs, giving you more flexibility for bass management and smoother low-frequency performance across the room.
- What kind of connectivity does the T 778 provide for modern video sources?
- It includes HDMI connectivity designed to support today’s video sources for a current, streamlined home theatre setup.
- Is the NAD T 778 a good fit for custom installation systems?
- Yes. It’s designed to integrate naturally into living spaces and professionally installed environments, with connectivity and system-compatibility that suit sophisticated installations.
NAD T 778 Downloads:
NAD T778 Manual
NAD T778 Quick Start Guide
NAD T778 Data Sheet
