AV7706: 11.2 Ch 8K Ultra HD AV Surround Pre-Amplifier with HEOS Built-in & Voice Control

• 11.2 channel XLR pre-out: 11.2 channel RCA pre-out
• 8K/60Hz and select 4K/120Hz pass-through support: 8 HDMI inputs (incl. 1 front) with full HDCP 2.3 support; 3 HDMI outputs (incl. Zone 2)
• 8K/60Hz pass-through and upscaling, Dynamic HDR and Quick Media Switching (QMS)
• Select 4K/120Hz pass-through, Variable Refresh Rate (VRR), Auto Low Latency Mode (ALLM) and Quick Frame Transport (QFT)
• The latest HDR format support including HDR10, HDR10+ (New in 2020), HLG, Dolby Vision, 4:4:4 color resolution and BT.2020, as well as Dynamic HDR (New in 2020)
• Advanced video processing with analog to HDMI conversion; SD to HD/8K upscaling
• Dolby Atmos, Dolby Atmos Height Virtualization Technology, DTS:X, DTS Virtual:X, IMAX Enhanced, and Auro-3D processing
• eARC (Enhanced Audio Return Channel) supports the most advanced surround and object-based audio formats via single HDMI connection between AVRs and compatible TVs
• Stream music from Internet Radio, Spotify Connect, Pandora, SiriusXM, Amazon Music HD, TIDAL, Deezer and more with Bluetooth, AirPlay 2 and HEOS Built-in
• Built-in Wi-Fi with 2.4GHz/5GHz dual band support
• Multi-room whole-home audio streaming with HEOS Built-in technology
• Supports voice assistant like Amazon Alexa, Google Assistant, Apple Siri and Josh.ai
• Decodes ALAC, FLAC and WAV lossless files up to 24-bit/192-kHz; DSD 2.8MHz and 5.6MHz tracks
• Marantz proprietary HDAM circuit boards, Current Feedback circuitry, 32-bit D/A converters, and Hybrid PLL Clock Jitter Reducer for more detailed, dynamic sound
• Audyssey MultEQ XT32, Dynamic Volume and Dynamic EQ, LFC, and Sub EQ HT
• Third-party integration and IR remote control, RS-232C serial port, and custom install support
• Seamless out-of-the-box experience with Quick Start Guide, guided Setup Assistant, and Marantz AVR Remote App

A Masterpiece Of Audio Architecture
The Marantz AV7706 features 11.2 channel XLR and RCA pre-outs, supports all 3D audio formats including Dolby Atmos, Dolby Atmos Height Virtualization, DTS:X, DTS Virtual:X, IMAX Enhanced, and Auro-3D. Experience audio playback with exceptional quality thanks to Marantz-proprietary HDAM modules and stream from Amazon Music HD, Pandora, Spotify, TIDAL, Deezer, and more with HEOS Built-in.

Advanced 11.2 channel Pre-amplifier
Experience a versatile home theater setup with the new Marantz AV7706 processor/pre-amplifier. It is built with masterful-quality external power amplification for the most demanding active speakers. Enjoy the audiophile sound you expect from Marantz combined with the latest video and audio decoding, as well as voice control with your favorite voice assistants.

Sophisticated Engineering
With 11.2 channel pre-outs on both conventional RCA sockets and balanced XLRs, the AV7706 is designed to work alongside high-quality external power amplifiers like the Marantz MM8077, MM7055, and MM7025.

Advanced 8K HDMI connectivity with eARC support
The AV7706 includes 8 HDMI inputs and 3 outputs for all your favorite sources. One dedicated 8K input supports 8K/60Hz or 4K/120Hz pass-through capability, 4:4:4 Pure Color sub-sampling, Dolby Vision, HLG, HDR10, 21:9 video, 3D, and BT.2020 pass-through while the latest HDCP 2.3 copy protection standard is supported on all HDMI inputs.

Full 3D Audio Support
Immerse yourself in multi-dimensional audio with the latest surround formats, including Dolby Atmos, Dolby Atmos Height Virtualization Technology, DTS:X, DTS Virtual:X, IMAX Enhanced, and Auro-3D.

Marantz HDAM & Current Feedback Topology
The AV7706 features exclusive Marantz Hyper Dynamic Amplifier Module (HDAM) technology that provide ultra-fast slew rate, true wideband performance, and maximum dynamic range for optimum sound quality.

The Next Chapter In Movie Entertainment
The new AV7706 offers the highest-quality, crystal-clear viewing experience. Enjoy your movies with 8K/60Hz pass-through or upscaling, as well the latest in HDMI technology like Dynamic HDR and Quick Media Switching (QMS), which is used in movies to eliminate video delay.

Info Sheet
