LUXMAN L-507Z Integrated Amplifier - silver

LUXMAN L-507Z Integrated Amplifier

The LUXMAN L-507Z Integrated Amplifier launches the brand’s next-generation Z Series with a refined blend of power, precision, and musicality. At its core is LIFES 1.0 (Luxman Integrated Feedback Engine System)—a newly developed amplification feedback engine designed to deliver a remarkably natural, dynamic presentation with lower distortion and greater realism. The New LECUA1000 88-step electronically controlled attenuator keeps volume adjustments smooth and transparent, while a high-stability power supply with a custom EI transformer and 80,000μF of filtering provides the current and control needed to drive demanding loudspeakers confidently.

Built for modern systems and serious analog listening, the L-507Z includes a high-quality MM/MC phono stage, balanced (XLR) inputs, and separate pre/power connectivity for flexible system building. Signature LUXMAN touches—like the large needle VU meters with LED backlighting and a 7-segment attenuation display—make daily use intuitive and satisfying from the listening seat. Add in upgraded headphone options (including a 4.4mm output) and a robust, resonance-conscious chassis, and the L-507Z becomes a centerpiece amplifier that’s as enjoyable to operate as it is to hear.

The LUXMAN L-507z is part of ListenUp's LUXMAN Integrated Amplifier Collection.

What It's Good At:

• Driving real-world speakers with ease thanks to high-current Class AB output power and strong control (high damping factor).
• Delivering natural, lifelike musicality with the next-gen LIFES 1.0 amplification feedback engine and reduced distortion.
• Preserving detail at any listening level using the New LECUA1000 88-step precision electronic attenuator.
• Elevating vinyl playback with a built-in MM/MC phono preamp designed for high-quality analog performance.
• Supporting premium sources and cables with balanced XLR inputs and high-quality RCA terminals built for audiophile interconnects.
• Upgrading headphone listening via dual outputs including 4.4mm and 6.3mm, designed to improve channel separation and imaging.

LUXMAN L-507Z Full Specifications:

• Type: Integrated amplifier
• Amplification feedback circuit: LIFES 1.0
• Amplification method: Class AB
• Rated output: 110W + 110W (8Ω)
• Rated output: 210W + 210W (4Ω)
• Output configuration: Bipolar 3-parallel push-pull
• Damping factor: 300
• PHONO (MM) input sensitivity / impedance: 2.5mV / 47kΩ
• PHONO (MC) input sensitivity / impedance: 0.3mV / 100Ω
• LINE input sensitivity / impedance: 180mV / 47kΩ
• BAL.LINE input sensitivity / impedance: 180mV / 79kΩ
• MAIN IN input sensitivity / impedance: 1.05V / 47kΩ
• PRE OUT output voltage: 1V
• Frequency response (PHONO): 20Hz to 20kHz (±0.5dB)
• Frequency response (LINE): 20Hz to 100kHz (within -3dB)
• Total harmonic distortion: 0.007% or less (8Ω, 1kHz)
• Total harmonic distortion: 0.03% or less (8Ω, 20Hz to 20kHz)
• S/N ratio (IHF-A) PHONO (MM): 91dB or more
• S/N ratio (IHF-A) PHONO (MC): 75dB or more
• S/N ratio (IHF-A) LINE: 105dB or more
• Volume adjustment: New LECUA1000 (88-step electronically controlled attenuator)
• Max. amount of tone control (BASS): ±8dB at 100Hz
• Max. amount of tone control (TREBLE): ±8dB at 10kHz
• Power supply: 230V~ (50Hz) / 115V~ (60Hz)
• Power consumption: 350W
• Power consumption (under no signal): 86W
• Power consumption (standby): 0.4W
• External dimensions: 440(W) × 178(H) × 454(D) mm
• Depth note: front side knob of 20mm and rear side terminal of 27mm included in depth
• Net weight: 25.4kg (main unit)
• Connections & terminals: Phono input terminals (MM/MC selectable); Line input terminals (1, 2, 3, 4); Balanced input terminals (1, 2) (XLR: No.1 GROUND, No.2 COLD, No.3 HOT); Main-in terminals; Pre-out terminals; Speaker terminals A, B (OFF / A / B / A+B); Headphone outputs φ6.3mm and φ4.4mm; Trigger in/out and Control in/out (φ3.5mm); AC inlet; Signal ground terminal; Phase inverters (1, 2)
• Accessories: Remote control (RA-17A); Power cable; Speaker terminal documentation
• Supported Y-lug terminal dimensions: Width of part a: 15mm or less; Width of part b: 8mm or more
• Note: Connection may not be performed depending on the shape of the Y-lug terminal

LUXMAN L-507Z Q&A:

What kind of speakers can the L-507Z drive?

With 110W + 110W into 8Ω and 210W + 210W into 4Ω, the L-507Z is built to drive a wide range of speakers with strong control and confident dynamics.

Does the L-507Z have a built-in phono stage for turntables?

Yes. It includes a high-quality phono input that supports both MM and MC cartridges, making it a strong foundation for vinyl playback.

Can I connect balanced XLR sources?

Yes. The L-507Z provides two balanced (XLR) inputs, ideal for high-end DACs, streamers, and other balanced-output components.

Can I use the amp as a preamp or power amp in a larger system?

Yes. With PRE OUT and MAIN IN terminals plus a separate function, the L-507Z can integrate into more advanced setups or support future upgrades.

What’s the benefit of LIFES 1.0?

LIFES 1.0 is LUXMAN’s next-generation amplification feedback engine designed to deliver more natural musical flow, strong dynamics, and lower distortion for a more lifelike presentation.

Is this amplifier good for headphones?

Yes. It includes both a standard 6.3mm headphone output and a 4.4mm output with independent grounding intended to improve separation and imaging.

How precise is the volume control?

The L-507Z uses the New LECUA1000, an 88-step electronically controlled attenuator designed to keep sound quality consistent across the full volume range.

Can I run two sets of speakers?

Yes. The speaker selector supports A, B, or A+B, and the rear panel provides dedicated terminals for Speaker A and Speaker B.

LUXMAN L-507Z Downloads:

LUXMAN L-507Z Catalog
