Kanto PF405 Pro TV Mount

Kanto PF405 Ultra Slim Fixed TV Wall Mount

The Kanto PF405 Ultra Slim Fixed TV Wall Mount is built for clean, high-end home theater and commercial AV setups that need a true low-profile look without giving up strength or service access. This ultra-slim fixed TV wall mount sits just 0.6 inches from the wall, supports most 50- to 90-inch TVs up to 125 lb, and fits VESA patterns from 100x100 to 800x600 for broad compatibility. Its extra-wide wall plate works across dual 24-inch or triple 16-inch stud spacing, while horizontal leveling and 1.6 inches of vertical adjustment help fine-tune placement in recesses, cabinets, and tight spaces. Quick-release arms, an integrated kickstand, solid steel construction, and a 10-year warranty make the PF405 a premium choice for sleek, stable, and service-friendly TV mounting.

What It's Good At:

• Creating an ultra-slim, gallery-style TV installation that keeps the display close to the wall
• Supporting large, heavy TVs with up to 125 lb of load capacity
• Handling a wide range of VESA mounting patterns up to 800x600
• Making off-center stud layouts easier to manage with horizontal shift and wide stud support
• Allowing easier cable access and servicing through quick-release arms and the integrated kickstand
• Delivering long-term durability with solid steel construction and a 10-year Pro Series warranty

Kanto PF405 Wall Mount Full Specifications:

• Product name: Kanto PF405 Ultra Slim Fixed TV Wall Mount
• Series: PRO
• Mount type: Fixed ultra-low-profile TV wall mount
• Recommended TV size range: 50" to 90"
• Weight capacity: 125 lb (56.7 kg)
• VESA compatibility: 100×100 to 800×600
• Profile from wall: 0.6" (1.6 cm)
• Vertical adjustment: 1.6" (4.1 cm)
• Post-install positioning: adjustable horizontal leveling / horizontal shift
• Wall plate width: 39.4" (100 cm)
• Stud compatibility: dual 24" stud spacing or triple 16" stud spacing; spans two or three studs
• Material: solid steel
• Finish: durable powder-coated finish
• Product dimensions (W/D/H): 100 x 1.6 x 76.3 cm (39.4" x 0.6" x 30")
• Product weight: 4.7 kg (10.3 lb)
• Shipping box dimensions (W/D/H): 117.1 x 12.8 x 8.5 cm (46.1" x 5" x 3.3")
• Shipping box weight: 5.8 kg (12.7 lb)
• UPC: 800152724966
• Warranty: 10-year manufacturer’s / Pro Series warranty
• Service features: spring-loaded quick-release arms and integrated kickstand
• Supported installation surfaces: wood stud walls and concrete walls
• Not intended for: steel stud walls or cinder block walls
• What’s included: PF405 Ultra Slim Fixed TV Mount, installation manual, and all mounting hardware for wood stud and concrete installation
• Hardware pack includes:
  • A: M6 x 10 mm screws (x4)
  • B: M6 x 14 mm screws (x4)
  • C: M6 x 20 mm screws (x4)
  • D: M6 x 35 mm screws (x4)
  • E: M8 x 10 mm screws (x4)
  • F: M8 x 14 mm screws (x4)
  • G: M8 x 22 mm screws (x4)
  • H: M8 x 30 mm screws (x4)
  • I: M8 x 35 mm screws (x4)
  • J: M8 x 50 mm screws (x4)
  • K: 2.5 mm spacers (x8)
  • L: 5 mm spacers (x8)
  • M: M6 washers (x4)
  • N: M8 washers (x4)
  • O: M8 x 50 mm lag bolts (x6)
  • P: M8 washers (x6)
  • Q: Concrete anchors (x6)
  • R: M5 x 6 mm screws (x4)
  • S: 3 mm hex key (x1)

Kanto PF405 Wall Mount Q&A:

What TV sizes does the PF405 support?

The PF405 is designed for most TVs from 50 to 90 inches.

What VESA patterns are compatible with this mount?

It supports VESA patterns from 100x100 up to 800x600, making it suitable for a wide range of large TVs.

How much weight can the PF405 hold?

This fixed TV wall mount supports up to 125 lb (56.7 kg).

How close does the TV sit to the wall?

The PF405 sits just 0.6 inches (1.6 cm) from the wall for a sleek, ultra-low-profile finish.

Can cables still be accessed after installation?

Yes. The quick-release arms and integrated kickstand make it easier to pull the TV away slightly for cable routing and maintenance.

Can the mount help with off-center studs or tight built-in spaces?

Yes. It offers horizontal adjustment for centering and 1.6 inches of vertical adjustment for fine-tuning the TV position in recesses, cabinets, or other tight spaces.

What wall types can this mount be installed on?

The PF405 includes hardware for wood stud and concrete installation. It is not intended for steel stud walls or cinder block walls.

Will it work with curved TVs or TVs that have recessed mounting holes?

It can. The included spacers are designed to help accommodate curved TVs, recessed mount holes, rear protrusions, and inputs that need extra clearance.

Kanto PF405 Wall Mount Downloads:

Kanto PF405 Wall Mount Manual
Kanto PF405 Wall Mount Product Sheet
Kanto PF405 Wall Mount Drawing
