Unlock Precision Sound: Focal Shape 50 Powered Studio Monitor

Unleash pristine sound quality with the Focal Shape 50, a powerhouse of versatility and functionality. Crafted in France, these studio monitors redefine nearfield monitoring with their compact design and extensive acoustic innovations. Ideal for spaces up to 130ft² (12m²), the Shape 50 delivers remarkable clarity and detail, making it a go-to choice for professionals and enthusiasts alike.

Focal Shape 50 Key Features:

• Low directivity tweeter ensures flexible listening positions
• Port-free design allows placement near walls for optimized space utilization
• Multiple settings for seamless integration into any studio setup
• Precision control across the entire frequency spectrum, including the very high end
• Flax sandwich cone technology delivers controlled bass and natural mid-range reproduction

Focal Shape 50 Specifications:

• Frequency Response (+/-3dB): 50Hz - 35kHz
• Maximum SPL (musical signal): 106dB SPL (peak @ 1m) Electronic Section:
• Inputs/Impedance: XLR: balanced 10kOhms, RCA: unbalanced 10kOhms with sensitivity compensation
• Midrange and Low Frequency Amplifier: 60W, class AB
• High-Frequency Amplifier: 25W, class AB
• Standby On: After approximately 30 minutes with no signal
• Standby Off: Signal detection > 3 mV
• Electrical Supply: 220-240V (T800mAL / 250V fuse) or 100-120V (T1.6AL / 250V fuse) Settings:
• High Pass Filter: Adjustable Full Range (45/60/90Hz)
• Bass (0 - 250Hz): Adjustable, +/-6dB
• Midrange/Bass (160Hz, Q=1): Adjustable, +/-3dB
• Power On/Power Off: On/off switch on rear panel
• Standby Consumption: < 0.5W
• Displays and Controls: LED for power on/off and standby Transducers:
• Woofer: 5" (13cm) Flax Cone
• Tweeter: 1" (25mm) 'M' profile Aluminum-Magnesium Cabinet:
• Construction: 0.6" (15mm) MDF
• Finish: Vinyl, real walnut, and black painting
• Dimensions (HxWxD) with four rubber feet: 12.3 x 7.5 x 9.5" (312 x 191 x 242mm)
• Weight: 20.7lb (6.5kg)

Elevate your studio experience with the Focal Shape 50, where precision meets performance for unparalleled sound reproduction.

Focal Shape 50 Downloads

Focal Shape 50 Spec Sheet
Focal Shape 50 Manual
