Audio Technica AT-LP70X Fully Automatic BT Belt Turntable (Bronze) - Clearance / Open Box
Audio Technica LP70XBT Turntable
The AT-LP70XBT Automatic Wireless Turntable is an ideal choice for beginners embarking on their audiophile journey. It combines the warm, analog audio experience of vinyl with the convenience of Bluetooth® technology. You can enjoy your records through Bluetooth-enabled speakers, headphones, or other devices, including those supporting the high-quality Qualcomm® aptX™ Adaptive audio codec. This user-friendly turntable plays both 33-1/3 and 45 RPM records and features a built-in switchable phono preamp, allowing connection to home stereos, powered speakers, or other components, with or without a dedicated phono input.
At the core of the AT-LP70XBT is a top-tier phono cartridge for unmatched, high-fidelity audio. Leveraging Audio-Technica’s industry-leading expertise, the AT-VM95C cartridge offers superior performance that sets it apart in its class. Integrated into the J-shaped tonearm, the AT-VM95C cartridge with a 0.6 mil conical stylus delivers excellent channel separation and low distortion for outstanding tonal quality. For a personalized listening experience, the stylus can be easily upgraded with other options from the VM95 Series, including elliptical, microlinear, or Shibata styli, offering unprecedented customization for a turntable in this category.
To ensure optimal sound performance, the AT-LP70XBT features a three-piece, anti-resonance chassis that provides a solid foundation to dampen unwanted noise for improved sound quality. The included AC adapter further reduces noise by moving the AC/DC conversion outside the chassis to minimize any unwanted interference.
Key Features:
- Simple, Intuitive Design: The AT-LP70XBT is easy to use, equipped with Bluetooth wireless technology for a straightforward connection to powered speakers and headphones. It plays 33⅓ and 45 RPM records automatically at the press of a button. The J-shaped tonearm features an integrated AT-VM95C cartridge, eliminating the need for installation, balancing, or other tonearm setup.
- Instant Upgrade Path: The unique AT-VM95C Integral Dual Moving Magnet™ phono cartridge is compatible with any VM95 Series replacement stylus, making it easy to replace or upgrade the stylus to enjoy a more refined sound.
- Versatile Playback: Plays 33-1/3 and 45 RPM records.
- Wireless or Wired Connectivity: Offers the flexibility of wireless Bluetooth or wired connections.
- Fully Automatic Operation: Simplifies the listening experience with automatic operation.
- Replaceable/Upgradable Stylus: Compatible with the AT-VM95 Series for easy upgrades.
The AT-LP70XBT ensures a high-quality audio experience with the convenience of modern technology, perfect for any new audiophile.
LP70XBT Specs
Turntable Specifications:
- Motor: DC motor
- Drive Method: Belt-drive
- Speeds: 33-1/3 RPM, 45 RPM
- Turntable Platter: Die-cast aluminium
- Wow and Flutter: < 0.25% (WTD)
- Signal-to-Noise Ratio: > 55 dB
Cartridge:
- Type: AT-VM95C Dual Moving Magnet Stereo Cartridge (non-removable)
-
Output Level:
- PHONO: 4.0 mV nominal at 1 kHz, 5 cm/sec
- LINE: 252 mV nominal at 1 kHz, 5 cm/sec
- Phono Pre-Amp Gain: 36 dB nominal, RIAA equalized
Power and Dimensions:
- Power Consumption: 1.6 W
- Dimensions: 400 mm (16") × 330 mm (13") × 110 mm (4.3") (W × D × H)
- Weight: Approx. 2.9 kg (6.4 lbs)
Accessories Included:
- Dust cover
- Felt mat
- Platter (with drive belt)
- Dust cover hinges
- 45 RPM adapter
- RCA audio cable (Approx. 1.0 m / 3.3')
- AC adapter (Approx. 1.5 m / 4.9')
AC Adapter:
- Type: FJ-SW1261200500DN
- Rated Input Voltage: 100 to 240 V AC
- Rated Input Current: 0.4 A max.
- Rated Frequency: 50 Hz / 60 Hz
- Rated Output Voltage: 12 V DC
- Rated Secondary Current: 0.5 A
- Cable Length: Approx. 1.5 m (4.9')
Tonearm:
- Effective Arm Length: 220 mm (8.7")
- Overhang: 18 mm (0.71")
- Tracking Error Angle: Less than 2.0°
Replacement Parts:
- Replacement Stylus: AT-VMN95C (sold separately)
- Replacement Belt: AT-LP70X exclusive belt (sold separately)
Bluetooth:
- Communication System: Bluetooth version 5.2
- Frequency Band: 2.402 GHz to 2.480 GHz
- Maximum RF Output: 2.5 mW EIRP
- Maximum Communication Range: Line of sight - approx. 10 m (33')
- Modulation Method: GFSK, Pi/4DQPSK, 8DPSK
- Compatible Bluetooth Profile: A2DP
- Support Codec: Qualcomm® aptX™ Adaptive audio, Qualcomm® aptX™ audio, SBC
Audio Technica LP70XBT User Manual
